AET Series
The AET Series is a series of desktop vibration isolators that bring together an entire high-performance vibration isolation system. At Meiritsu Seiki, many of our previous desktop vibration isolators have been combined into a series. As a result, the AET Series, which combines these vibration isolators with steel honeycomb surfaces tables, consists of desktop air suspension vibration isolators are optimal for optical experiments using a small surface area.
| Model | Description |
|---|---|
| AET-0405 | • Natural frequency : 2.5-2.7HZ • Vibration isolation method : Special diaphragm air spring • Damping method : Air damping using orifices • Load weight(kg) : 60 • Table dimensions(mm) : 430x530x50 • Machine Heights(mm) : 115.5 • Machine weight(kg) : 30 • Stndard accessories : S-type:Urethane tube 6mmx3m, Pipimg joint(PT1/4 male threads)x1 |
| AET-0506 | • Natural frequency : 2.5-2.7HZ • Vibration isolation method : Special diaphragm air spring • Damping method : Air damping using orifices • Load weight(kg) : 60 • Table dimensions(mm) : 530x630x50 • Machine Heights(mm) : 115.5 • Machine weight(kg) : 39 • Stndard accessories : S-type:Urethane tube 6mmx3m, Pipimg joint(PT1/4 male threads)x1 |
| AET-0605 | • Natural frequency : 2.5-2.7HZ • Vibration isolation method : Special diaphragm air spring • Damping method : Air damping using orifices • Load weight(kg) : 60 • Table dimensions(mm) : 630x530x50 • Machine Heights(mm) : 115.5 • Machine weight(kg) : 39 • Stndard accessories : S-type:Urethane tube 6mmx3m, Pipimg joint(PT1/4 male threads)x1 |
| AET-0806 | • Natural frequency : 2.5-2.7HZ • Vibration isolation method : Special diaphragm air spring • Damping method : Air damping using orifices • Load weight(kg) : 60 • Table dimensions(mm) : 630x530x50 • Machine Heights(mm) : 115.5 • Machine weight(kg) : 50 • Stndard accessories : S-type:Urethane tube 6mmx3m, Pipimg joint(PT1/4 male threads)x1 |
| AET-1007 | • Natural frequency : 2.5-2.7HZ • Vibration isolation method : Special diaphragm air spring • Damping method : Air damping using orifices • Load weight(kg) : 80 • Table dimensions(mm) : 1000x750x50 • Machine Heights(mm) : 115.5 • Machine weight(kg) : 72 • Stndard accessories : S-type:Urethane tube 6mmx3m, Pipimg joint(PT1/4 male threads)x1 |
AVT Series
There are desktop vibration absorption boards featuring advanced air suspension type vibration isolators. All vibration isolation functions are incorporated in a compactly designed body. Sixteen models, diversified in characteristic, are available. The designs are sophisticated considering operation conditions sufficiently. The high-performance AVT Series, incorporating stage-of the-art technology, will fulfill all your needs. We are confident in recommending the AVT Series for small-medium-scale precision machines and those for machining minute parts. The AVT Series assures their maximum potentials by isolating them from vibration.
| Model | Description |
|---|---|
| AVT-0405 | • Natural frequency : 2.5-2.7HZ • Vibration isolation method : Special diaphragm air spring • Damping method : Air damping using orifices • Leveling method : S type : Automatic leveler keeps the surface table level automatically.N type : Hand operated with an attached hand pump. • Load weight(kg) : 55 • Top plate dimensions (mm) : 430×530 • Dimensions (mm)) : 430x548x60 • Weight (kg) : 18 • Standard accessories : S type : urethane tube φ6x3m,piping joint (PT1/4 male threads)x1. N type : hand pump, screw driver for adjustment of air supply and exhaust valve, height gage. |
| AVT-0506 | • Natural frequency : 2.5-2.7HZ • Vibration isolation method : Special diaphragm air spring • Damping method : Air damping using orifices • Leveling method : S type : Automatic leveler keeps the surface table level automatically. N type : Hand operated with an attached hand pump. • Load weight(kg) : 60 • Top plate dimensions (mm) : 530×600 • Dimensions (mm)) : 530x618x60 • Weight (kg) : 23 • Standard accessories : S type : urethane tube φ6x3m,piping joint (PT1/4 male threads)x1.N type : hand pump, screw driver for adjustment of air supply and exhaust valve, height gage. |
| AVT-0605 | • Natural frequency : 2.5-2.7HZ • Vibration isolation method : Special diaphragm air spring • Damping method : Air damping using orifices • Leveling method : S type : Automatic leveler keeps the surface table level automatically.N type : Hand operated with an attached hand pump. • Load weight(kg) : 60 • Top plate dimensions (mm) : 600×530 • Dimensions (mm)) : 600x548x60 • Weight (kg) : 23 • Standard accessories : S type : urethane tube φ6x3m,piping joint (PT1/4 male threads)x1.N type : hand pump, screw driver for adjustment of air supply and exhaust valve, height gage. |
| AVT-0806 | • Natural frequency : 2.5-2.7HZ • Vibration isolation method : Special diaphragm air spring • Damping method : Air damping using orifices • Leveling method : S type : Automatic leveler keeps the surface table level automatically.N type : Hand operated with an attached hand pump. • Load weight(kg) : 70 • Top plate dimensions (mm) : 800×600 • Dimensions (mm)) : 800x618x60 • Weight (kg) : 32 • Standard accessories : S type : urethane tube φ6x3m,piping joint (PT1/4 male threads)x1.N type : hand pump, screw driver for adjustment of air supply and exhaust valve, height gage. |
