Spec
Ar-Ion Lasers
Fields of Application
- The lasers are designed for multipurpose solutions for scientific and
OEM applications: - Confocal Laser Scanning Microscopy
- DNA Sequencing
- Flow Cytometry
- Analytical Chemistry
- Fast-Flow-Rate Particle Measurements
- Digital Imaging
- Medical
- Basic Research Entertainment
Model | Description |
---|---|
LGK 7801 BM06 | .Wavelength [nm]: 454.5 – 496.5 .Min. output power free beam[mW]: 20 .Beam Diameter: 0.65 .multi line |
LGK 7872 BM | .Wavelength [nm]: 454.5 – 496.5 .Min. output power free beam[mW]: 30 .Beam Diameter: 0.65 .multi line |
LGK 7801 ML06 | .Wavelength [nm]: 454.5 – 514.5 .Min. output power free beam[mW]: 25 .Beam Diameter: 0.66 .multi line |
LGK 7872 ML | .Wavelength [nm]: 454.5 – 514.5 .Min. output power free beam[mW]: 40 .Beam Diameter: 0.66 .multi line |
LGK 7872 BL | .Wavelength [nm]: 454.5 / 457.5 .Min. output power free beam[mW]: 5 .Beam Diameter: 0.64 .single line |
LGK 7872 BL01 | .Wavelength [nm]: 454.5 / 457.5 .Min. output power free beam[mW]: 5 .Beam Diameter: 0.64 .single line |
LGK 7801 M6 | .Wavelength [nm]: 488 .Min. output power free beam[mW]: 12 .Beam Diameter: 0.66 .single line |
LGK 7872 M | .Wavelength [nm]: 488 .Min. output power free beam[mW]: 20 .Beam Diameter: 0.66 .single line |
LGK 7801 GL6 | .Wavelength [nm]: 514.5 .Min. output power free beam[mW]: 10 .Beam Diameter: 0.64 .single line |
LGK 7872 GL | .Wavelength [nm]: 514.5 .Min. output power free beam[mW]: 15 .Beam Diameter: 0.64 .single line |
LGK 7872 GL01 | .Wavelength [nm]: 514.5 .Min. output power free beam[mW]: 15 .Beam Diameter: 0.66 .single line |
LGK 7890 A Rev. 01 | .Wavelength [nm]: 454 / 457 / 514 .Min. output power free beam[mW]: 4 @ 454 / 457, 10 @ 514 .Beam Diameter: 0.65 / 0.69 .dual line |
Download |
---|
lasos_arion-laser.pdf |
